4EFEJay

4EFEJay's EP91 Sprint Project

Recommended Posts

Yes that will give you low down but you will lose upper rpm power. a smaller free flowing diameter exhaust would be better as none of the gases will be getting caught up in silencers or bungs. It creates a turbulent flow which isnt power efficient. (i dont mean to go on about it but you will notice a massive difference when you do change it)

Yeah, looking for a 2" exhaust. But can't seem to find any for the EP91. I guess custom is the way to go.

Share this post


Link to post
Share on other sites

Definalty mate, not too expensive either. Have you got any pics of the car as it stands now?

Share this post


Link to post
Share on other sites

Yeah custom is the only way really! 2" pipe is cheap enough too! Plus, im sure you will have a buyer for the exhaust you currently have fitted when you do.


Share this post


Link to post
Share on other sites

Well I'm resurrecting my build thread due to a few *small* updates and changes. I apologise for not keeping it up to date for a long time, buying a house. Moving 200 miles across the country and not really doing much with it meant lack of updates. But I’m back.

Having won 2 Championships with the Starlet as it was in 1.3NA form. I decided I needed more power and an update.

The problems I faced was if I just stuck a turbo on my NA engine were blowing it up as I got greedy with boost and it puts me in a class in the Toyota Sprint with other cars that would be far out of reach to even compete due to how the regs and engine sizes work.

Long story short… after spending a winter porting, polishing and getting it back together to find it just smoked badly, twice. I decided a different route was the only option. Having run out of time with only 1 week to go before the first Sprint, I decided to just get a stock engine and sling it in for now. I ran the whole year on a free engine I knew little history about and managed to win the championship again. But now I really was after more power and wanted to make sure the effort was worth it!

Doing some research and looking around I realised the best way to go class and regs wise was a naturally aspirated bigger engine up to 1.8. The Yaris T Sport 1NZ-FE engine was an option or a 5efhe. But this was almost impossible to find al the parts needed to make this happen. The only other real contender was the 2ZZ-GE from a Corolla T Sport. The 2zz-ge is also only around 10 - 15kg heavier than 4efe with it being an Aluminium block. With moving the battery to the rear, the front end weight wasn’t much heavier than stock.

I spoke with Fensport Performance and they agreed it would be a fantastic idea and were happy to take it on.

I sourced a MOT failure Corolla T sport with a failed clutch which I managed to get very cheap, it was low mileage, engine was in great condition and been serviced very well. Both cars dropped off at Fensport for some initial measurements, plans and different ways we could make it fit and work.

We decided to try and use as much stock parts from the corolla as possible. Being a sprint and track car it needed to be easy to fix, quick to fix and not use many custom parts. Also being a track car we didn’t mind widening the track a little bit and using standard Corolla drivetrain up front. So we could use standard hubs, driveshafts, mounts and brakes. Then running wider arches to cover the wheels that we’re now sticking out a bit. 50mm spacers and more aggressive offset wheels on the rear meant the back came out to match the front.


The initial plan was to use the standard management from the corolla to run the engine. But once we started going down this route it was starting to look like a lot of work, to even just get the original loom out, cut down and spliced in with starlet was considerable labour time. The ECU then needs to be sent off to be unlocked so the starlet immobiliser works. Or start swapping over ignition barrels etc. We decided to just go for a standalone ECU and new loom as this worked out far easier in labour but gave us much more flexibility. We could gain more power, some nice track features and safety. ECU we chose was the Link G4+ Monsoon. This gives us all the tuning we require and twin VVTLI control.

As with all these kind of builds and engine swaps it wasn’t so straight forward, a lot of custom fab work, fitting and adjusting to get it all to sit and align correct. Making sure everything was strong, safe and could take the impact of some serious track time. It did mean we missed the first 2 rounds of the Championship, however I had a spare car to use so managed to retain some points, plus you can drop 2 rounds as part of the championship anyway.

The time came and they told me it was ready, mapped and tested the day before the Anglesey round. We quickly got an MOT on it, insured and taxed I went and picked it up!

Driving it home on the roads was an absolute hoot. The way it picks up speed is just insane, it revs right round to over 8k rpm and just keeps accelerating, loads more torque low down than standard map in the standard car! Full Custom exhaust sounds incredible. I wasn’t expecting it to be quite so fast, I drove the Corolla T sport and was impressed but all the action seemed to be in lift above 6200rpm. But with the mapping and bringing in the lift earlier it's just a blast to drive now. With only around 850kg too it just picks up and feels epic. It tops out the stock starlet speedo in 4th gear and carries on pulling through 5th and 6th.

The next day at anglesey I went and beat my previous lap time by 11 seconds straight off. This was a damp lap with very limited seat time. Easily another 5 seconds in the car once I’m used to it.

It’s begging for an LSD now and some new tyres. Handling wise it was fantastic, other than the fact I was missing all my braking points and turn ins. The Anglesey back straight out of Church and up to Rocket with the 1.3NA I was hitting a top speed of around 90mph if I was lucky and the wind wasn’t against me at the top of the hill. This year I was closing on 120mph before I bailed and got on the brakes. Corolla brakes stopped it great but there wasn’t many corners I was getting right. Missed one corner completely and had to bail on the grass. But it’s a learning curve and with it being a wet day it was hard to really push and find where the grip and edge was. A little bit of understeer mainly caused by the extra speed I was carrying and the track being damp. An LSD should help a lot. Hairpins was just a riot for the inside tyre!

But I can’t thank Fensport Performance enough for their hard work, mapping and push to get it done. It realistically only had about 4 weeks work on it. Rest of the time was planning, ordering parts, awaiting workshop space etc. They’ve done a brilliant job, it drives fantastic, didn’t have to put a spanner on it all day and Tom Hudson at Fensport has done a superb job on the mapping! I’m actually tempted to put full size wing mirrors on it and drive it about on the road as a daily for a bit!

Below are some photos, a couple of youtube videos. Bare in mind the youtube video was probably my 4th time driving the car in anger on track and the first time I’d driven it on a *drying track*. My lines, turn in, braking points are all bad and a mess.



61724906_2758060024267897_64161454804927

62132061_2758060110934555_52264241549279

61725331_2758060270934539_68267904003347




My Fastest (Still very messy) Lap.



And my small Whoops where I missed the breaking point completely. Realising I was doing 40mph more than I had been the previous years!

P.S - I’m now also trying to find a 6 point cage if anyone has one they want to sell, ideas on where to get one or fabricated. I want to try and avoid the 8-10 week deliverey, expensive cusco bolt in one.

Cheers.

Share this post


Link to post
Share on other sites

This forum need a like button, that 2Z sounds great!

Share this post


Link to post
Share on other sites

This is exactly what I want to do and had no idea that Fensport would take on the work! Fantastic car mate

Share this post


Link to post
Share on other sites

Got sent a few pics of this in whatsapp the other day! Like this build, that rear under brace / mount looks ace.

Share this post


Link to post
Share on other sites
1 hour ago, daniel_g said:

Got sent a few pics of this in whatsapp the other day! Like this build, that rear under brace / mount looks ace.

Nice! Of it out and about or the Fensport pics?

Underbrace was required to mount the gearbox and it also strengthens the arms that come down from the chassis to stop it splitting and supports the extra width!

Share this post


Link to post
Share on other sites

The pics from Fensport.

Its a good idea, aswell as the modified master cylinder.

Share this post


Link to post
Share on other sites

this looks like a fun little car and i think this swap will become quite popular.

what race series are you running?

good to see people still updating build threads on here too. interested for more updates with this

Share this post


Link to post
Share on other sites

Awesome swap, looks nice and tidy too does it sit low or is it not too bad?

Any idea what the short master cylinder is from? I could do with something like that on mine to clear the airbox.

Not that you need it with a standalone with safetys built in but you should be able to get the temp gauge working with a 4efe temp sensor plumbed in somewhere.

Cracking motor mate look forward to seeing more from it!

Share this post


Link to post
Share on other sites

This is awesome. It looks like the boys at fensport did a great job!

your username is broken now tho 😎

Share this post


Link to post
Share on other sites
On 6/6/2019 at 12:18 PM, snails ep91 said:

what race series are you running?

I've built it for the Japanese Sprint Series and the Toyota Sprint Series Championship. These were the main reason for not just strapping a turbo to it. As that then puts you in some classes that don't really make sense for a 1.3 turbo starlet.

13 hours ago, morgey said:

Awesome swap, looks nice and tidy too does it sit low or is it not too bad?

Any idea what the short master cylinder is from? I could do with something like that on mine to clear the airbox.

Not that you need it with a standalone with safetys built in but you should be able to get the temp gauge working with a 4efe temp sensor plumbed in somewhere.

Cracking motor mate look forward to seeing more from it!

Doesn't sit too low. With the wide track I've raise the coilovers up a little more to give some more clearance. Sump is just a touch shorter than the bottom gearbox mount, so if I do hit anything it should be that first. Although we're still going to make a sump guard for it.

Master cylinder is from I believe an IQ or an Aygo (Can't remember which one) When just adapter it for remote reservoir. Everything we tried was very close with in like 5mm with top mounted reservoir. So remote is the best way to go.

Yeah, I can put a fitting in the top hose and just screw the stock sensor into it.



12 hours ago, Socks said:

This is awesome. It looks like the boys at fensport did a great job!

your username is broken now tho 😎

Yeah they did awesome job, it seems really solid build and very well done! Didn't think about the username! I should fix that really haha!

Share this post


Link to post
Share on other sites

I'm now after a rear anti-roll bar.

Does anyone have experience of these? If they make a good difference, and running them with the anti-dive kit whittline do?



Share this post


Link to post
Share on other sites
2 hours ago, 4EFEJay said:

I'm now after a rear anti-roll bar.

Does anyone have experience of these? If they make a good difference, and running them with the anti-dive kit whittline do?



I've just fitted a custom rear arb can't report back on handling till after my next race. But in should help a lot from what I've heard

Share this post


Link to post
Share on other sites

Well in autox you experience some suspension bind with the alk and us tercel guys usually remove it. It is kinda like a chirp chirp chirp while going around some corners. The alk does help alot with wheelhop though. I can tell you that from experience. You might benefit more with some bumpsteer plates that is added on to the control arm. It all really depends on how your car is setup though.

Share this post


Link to post
Share on other sites

We were racing at Croft this weekend. 2nd in Class but it was a tough day as the weather kept changing. Everyone seemed to get different weather and I always seemed to go out just after or as it rained!

Lost to a MX5 on silly grippy tyres and some serious suspension work!

I'm definitely after an ARB and Anti Lift kit now!

Video from the weekend:
